It’s pretty easy to get a webcam to stream in Ubuntu, or indeed any Debian distribution. In this example I’m using Ubuntu 10.04 (Karmic) and a Microsoft Lifecam VX-1000 web cam.
First get root access with the usual command.
$ sudo bash
[sudo] password for user: *********
Next open up a terminal window and install webcam-server as follows:
$ apt-get install webcam-server
Now go to the /dev directory and list the contents. From your home directory type:
$ cd ..
$ cd ..
$ cd /dev
You’ll now see a list of files that will look similar to this:
input ram11 tty32 vcsa4
kmsg ram12 tty33 vcsa5
log ram13 tty34 vcsa6
loop0 ram14 tty35 vcsa7
loop1 ram15 tty36 tty7 vcsa8
loop2 ram2 tty37 tty8 zero
loop3 ram3 tty38 tty9
loop4 ram4 tty39 ttyS0
Now plug in your webcam into one of the USB ports, wait a couple of seconds then type the same command again:
You should see another file has appeared that starts with video. Mine’s shown up as video0 as it’s the first video device connected to the system. If you have an integrated webcam, subsequent webcam handles will be incremented, i.e. video1, video2 etc..
Now to start the webcam-server daemon, type the following:
$ webcam-server -d /dev/video0
If it’s working, you’ll just see the cursor continue to blink. To confirm that the daemon is running, go to http://localhost:8888. You should see a JPEG image with a timestamp, showing what your webcam can see.
If not, check the terminal for errors.
libv4lconvert: Error decompressing JPEG: fill_nbits error: need 6 more bits
If you see the above message or similar, you’ll need to try and run your webcam in compatibility mode, as follows:
$ LD_PRELOAD=/usr/lib/libv4l/v4l1compat.so webcam-server -d /dev/video0
Now check http://localhost:8888 again, and all things being well, you’ll see the JPEG snapshot. (if not, check the Ubuntu forums to check that your device is supported)
Now as that’s not strictly speaking a stream, there’s one last thing to do.
$ cp /usr/share/doc/webcam-server/applet/* /var/www/
This will copy some files, including the Java streaming applet, to your web accessible directory, /var/www. Now if you go to http://localhost/webcam.html, you’ll see an applet load, followed by a live stream from your webcam.
Note: The useful thing about this, is that you can run as many daemons as your system can handle, so you can plug in a number of webcams to the same system and with some additional webcam-server switches, you can assign each camera to a different port.
